- DIY Supplies: ELECTRICAL
- Brand Name: LanYuXuan
- Origin: Mainland China
- Certification: CE
- Place of Origin: Shanghai, China
- Brand Name: Sunbright
- Model Number: SUN-808F
- Power Source: Electricity
- Warranty: 2 years
- After-sale Service: Return and Replacement
- Material: Metal, Plastic
- Shelf Life: 2 years
- Quality Certification: ce
- Instrument classification: Class II
- Safety standard: None
- Type: Portable Ultrasonic Diagnostic Devices
- Display: 5.6" LCD
- TGC: 8 segments
- battery: li-ion
- battery work time: more than 3 hours
- Cineloop: 192 frames
- USB port: 2
- Frequency: 2.5MHz-10.0MHz
- Probe Type: convex probe, linear probe, transvaginal probe, micro-convex probe
- Application: general, OB/GYN, small organs, or Veterinary etc.
Sales Manager: Miss Alice Zhong
WhatsApp: +86 18890035203
Wechat: zyy17608400048
Email: 1225048339@qq.com
Mobile number: +86 17608400048
Fast Description
1. Light weight of 0.5 kg, very convenient to carry out.
2. Crystal clear with high resolution image display
3. Dismountable battery which can work more than 3 hours.
4. 192 frames of cine-memory and 1024 images permanent storage.
5. Realized read-write function through USB connection and SD connection
6. Other performance is as the same as the laptop computer, such as power save mode, touch mouse and so on.
7. Professional software: General software, Obstetrics software, Cardiac software.
8. Video-out port, connect with computer, external monitor and HP printer directly
9. Supports the colored surface, the ultrasonic area pseudo-color.
10. Individual battery recharger for option
Softwares
This Ultrasonic diagnostic instrument (here in after referred as instrument) using 3.5 MHz electronic convex array probe,adopts full digital beam former(DBF); real-time dynamic aperture imaging (RDA); full digital dynamic receive focusing (DRF); frequency conversion; 8 segments TGC; dynamic digital filtering; dynamic digital filtering; image enhancement; line correlation, frame correlation, point correlation, linear interpolation and many other image processing technology, etc.;
Display modes as B, B/B, 4B, B+M and M, image multiplying factors of ×0.8, ×1.0, ×1.2, × 1.5,×1 .8, ×2.0 under the B mode;
With 128 a large memory and offers permanent storage, cine loop in real time; 256 images available after diagnosis of real-time playback or by image viewer,
Has measurements of distance, area, circumference, heart rate, gestational weeks(BPD,GS,CRL,FL,HC,OFD,TTD,AC 8 measurement kinds) and so on;
Chinese and English transformation; 16 kinds of pseudo color processing; real-time clock; serial number of medical record; many note functions as full-screen character noting;
Adopts large scale integrated circuit FPGA, MSF, mass memory, surface mounting technology and so on.
Technical Specifications
|
Scanning mode
|
electronic linear array, electronic convex array
|
|
Imaging model
|
B, B/B, B/M, M, 4B
|
|
Gray scale
|
256 levels, four selectable gamma curve
|
|
Transducer frequency
|
2.5-8.5 MHz
|
|
Magnification
|
×0.8, ×0.9, ×1.0,×1.1,×1.2,×1.3, ×1.4,×1.5
|
|
Permanent storage
|
1024
|
|
Cine loop
|
≥400 framedayudengyu
|
|
Sound Power
|
8 grades from 0-7
|
|
Dynamic Range
|
Adjustable from 30-75
|
|
USB Ports
|
2
|
|
IP set
|
8
|
|
Body Mark
|
35 kinds
|
|
Pseudo color
|
5 kinds
|
|
Image Processing
|
Up/Down, Left/Right, Black/White, Frame correlation Edge enhancement, Scroll
|
|
Measurement
|
Circumference, Area, Volume, Heart ratio, Velocity, OB
|
|
Focus
|
Number and location of the focus can be adjusted
|
|
Puncture
|
Puncture guide line
|
|
TGC
|
Adjustable, Near field, Middle field and Far field are adjustable from 39-99
|
|
Body Marks
|
35
|
|
IP set
|
Hospital’s name, Date, Time, Formula of Fetus’ weight and Pseudo color
|
|
Image store format
|
BMP, DICOM
|
|
Formula of Fetus’ weight
|
OSAKA, TOKYO1, TOKYO2, MERZ
|
|
|
Frame correlation, Edge enhancement, Dynamic range, center line, scan angle Puncture
|
|
Voltage
|
AC85V-265V
|
808F for main unit +one convex probe++Lithium battery +leather case with neck belt+Aluminum suitcase
5.0″LCD with high resolution
Measurement software for human or veterinary
Two USB ports
One video port
One power inlet
One convex probe(3.2M R50)
Or one rectal probe
Plenty of measurement & calculation software packages
18 months warranty since ex-factory date for main unit
12 months warranty since ex-factory date for probes
